Isenberg 196.4301MB 3/4x22 Thermostatic Valve with 3-Way Diverter and Trim Matte Black

Description

The diverter handle on the top diverts the flow from each of the three outputs of the valve. Depending upon the shower model, trims can be of different shape and size, varying from square to circular shower handles. Each port has full volume control capability. VALVE INSTALLATION – As the valve is installed, care should be taken to maintain a proper distance from the back of the valve to the finished tile which should be between 2.77” and 3.44” inches [Rough In Spec]. Isenberg 3/4′′ Thermostatic Valve with 3-Way Diverter and Trim 196.4301 Product Description SPECIFICATIONS: Solid Brass Valve & Trim Includes Thermostatic Valve Diverts water between 3 outlets. The trim plate is used to cover the wall. CUT OUT DIMENSIONS – The cut out in wall should be 6.49” x 4.44” Inches which is properly covered by the trim plate. TRIMS – The trims comprise of a well-finished cover plate and handle knobs. The top handle is capable of controlling the volume of water from full flow to a trickle. The anti-scald temperature stop ring should be fitted tightly over the valve (tapping using a rubber mallet might be required) for it to function properly. With the help of this ring, the temperature of the water is regulated. In case, the tile is thicker or valve installed in the wall is too deep, extension kits are available and can be used for elongating both handles of the valve. Product Documents SPECIFICATION SHEET PARTS DIAGRAM Installation Installation Documents.

Key Features

• The anti-scald temperature stop ring should be fitted tightly over the valve (tapping using a rubber mallet might be required) for it to function properly.
• ANTI-SCALD RING – Over the temperature control knob, is an anti-scald temperature stop ring which is a safety feature in this thermostatic value.
• Isenberg 3/4′′ Thermostatic Valve with 3-Way Diverter and Trim 196.4301 Product Description SPECIFICATIONS: Solid Brass Valve & Trim Includes Thermostatic Valve Diverts water between 3 outlets.
• TRIMS – The trims comprise of a well-finished cover plate and handle knobs.
• The top handle controls water diversion between the 3 water output ports.
• VALVE INSTALLATION – As the valve is installed, care should be taken to maintain a proper distance from the back of the valve to the finished tile which should be between 2.77” and 3.44” inches [Rough In Spec].
