Instek GDS-1072A-U 70 MHz Digital Storage Oscilloscope

Description

Although, the GDS-1000B series is under the category of general purpose oscilloscope, the full functionalities within this simple-in-look oscilloscope, including parameter measurement, cursor indication, digital voltage meter, and data logging, surpasses the same category 1000 series oscilloscopes in the market. All applications of the GDS-1000B series can be applied to the educational field and the fundamental R&D units of the industrial sector.The GDS-1000B series features three bandwidth selections 100 MHz, 70 MHz, 50MHz and equips with analog signal input terminals by four or two channels ( 50MHz only equipped 4 channels input ). The maximum sampling rate for each single channel is 1GSa/s, and the memory depth is 10Mpts per channel independently. The waveform update rate is 50,000wfms/s, which helps users to precisely observe the detailed waveform variation. Additionally, 7” WVGA color LCD display and the 256 color gradient display function together allow waveforms to be observed with the senses of transparency and gradation. With respect to the horizontal time scale adjustment knob and trigger level adjustment knob, GW Instek provides a very thoughtful design the zero key function, which allows engineers to work more effectively.For mathematical analysis mode, 1Mpts FFT signal display makes the dull frequency domain signal analysis more delicate. The maximum sampling rate for each single channel is 1GSa/s, and the memory depth is 10Mpts per channel independently.

Key Features

• The GDS-1000B series oscilloscope also provides Open Wave connection software, which allows users to conduct waveform observation and data storage controlled by remote PC.
• Additionally, 7” WVGA color LCD display and the 256 color gradient display function together allow waveforms to be observed with the senses of transparency and gradation.
• The waveform update rate is 50,000wfms/s, which helps users to precisely observe the detailed waveform variation.
• The maximum sampling rate for each single channel is 1GSa/s, and the memory depth is 10Mpts per channel independently.
• All applications of the GDS-1000B series can be applied to the educational field and the fundamental R&D units of the industrial sector.The GDS-1000B series features three bandwidth selections 100 MHz, 70 MHz, 50MHz and equips with analog.
• With respect to the horizontal time scale adjustment knob and trigger level adjustment knob, GW Instek provides a very thoughtful design the zero key function, which allows engineers to work more effectively.For mathematical analysis mode.
